RV Rider E-Bike Rack
The RV Rider bike rack for RV's, motorhomes, and fifth wheels carries 2 E-Bikes (up to 80 lbs. each) on the back of an RV Motorhome, a 5th wheel, or a flat towed vehicle. Special features include universal heavy-duty wheel holders for heavy load carrying capacity. These wheel holders can fit any tire up to 5" wide and include a ratchet wheel strap. Locking frame grabbers secure the bikes in place. The frame grabbers can attach to a bike's frame or seat tube with a diameter range of 1"- 2", therefore Bike Adapters are not needed and should not be used. A locking cable and keyed alike hitch pin secure the bikes to the rack and the rack to the vehicle. The bike rack folds up when not in use and can tilt down for rear cargo access.
A double-walled receiver tube handles the extra weight of the electric bikes. An included hitch tightener reduces motion inside the hitch (the receiver hitch must have a flange). A minimum class 3 trailer hitch is required to use this bike rack.
This bike rack is not compatible with bumper pull, travel trailers or bumper mounted hitch receivers.
Class A, B & C RV Motorhome:
- Capacity: Two Bikes (Max. 80 lbs. per bike)
- Hitch Size: 2” only (Do not use a 1 ¼” -2” hitch adapter)
- Maximum bike wheelbase: 60”
- Minimum wheelbase: 36"
- Maximum tire width: 5"
- Features extra heavy duty wheel holders (Now with ratchet straps and rim protectors), an internally reinforced frame, and an external brace for heavy load carrying capacity
- Includes keyed-alike locking hitch pin, 8’ security cable, and locking frame grabbers
- The frame grabbers on this rack can hold step through bikes by the seatpost, therefore Bike Adapters are not needed and should not be used.
- Now includes two Small Wheel Adapter (SW-ADP-U) for 20" Fat tire bikes rear wheels to prevent derailleur hanger interference (You will only need one per bike)
- Not to be used with any 1-1/4" - 2" Adapter
- Not to be used with any Hitch Extension longer than 8"
- Not to be used on any trailer
- Not intended for use with motorized gasoline bicycles, mopeds, motorcycles or 3 wheel bikes (trikes), or electric scooters
- The RV Rider is the only rack that can be used on front hitches
- Rack Weight: 63.5 lbs.
- Limited Lifetime Warranty
- Minimum Trailer Hitch Tongue Weight: 350 lbs
- Minimum Vehicle Length: 24'
- Minimum GVW: 5,000 lbs
- Double Axle Required
About Hollywood Racks
Exceptional Bike Racks with Superior Stability
3rd Generation Family-Owned Doing What We Love the Most
Locally Owned & Operated in Los Angeles, California
Well built and good for our 2-74lbs Magnum eBikes.
Long term RV park. Won't move til 2/15 I have to have it ready by then. Later.
Will be installing my RV Rider rack on our 5th wheel camper. Took it for a test-spin on our tow vehicle. Once I got through the initial setup, I'm finding the bike realtively easy to load and secure. Solid construction and pretty easy to assemble. The rack itself is pretty heavy and it helps if you have a helper to insert into the 2" receiver, but after that, it's a breeze. Also love the multiple points of security on this rack. I would recommend to anyone with a towable RV.
IT WORKED GREAT
Very solid rack.
